225

ENGINES

COOLING SYSTEM SPECIFICATIONS

B1GP0BWP

(1) Header tank

(2) Coolant pump

(3) Bleed screw of heater matrix

(4) Heater matrix

(5) Coolant outlet housing

(6) Bleed screw of coolant outlet housing

(7) Thermostat

(8) Cooling radiator

Engine: KFU
