CLUTCH

GEARBOX

DRIVESHAFTS

273

NOTE: (*) DVAR: Equipped with a Double Damping Flywheel with springs in the radial position in relation to the axis of the crankshaft.

NOTE: (**) DVA: Equipped with a Double Damping Flywheel with springs arranged concentrically.

CLUTCH SPECIFICATIONS

Engine type 9HX 9HY* 9HZ* RHR**

Gearbox type BE4/5L ML6C

Supplier LUK

Mechanism / Type 235 P 4800 235 P 7400

Clutch disc

Identification 4

of the springs (White)

Number of splines 18

Ø of lining. Ext/Int 234/165 235/150

Quality of lining 810 DS

1.6 HDi 16V 2.0 HDi 16V

Diesel

UK-C4-page271-321-2004 15/11/04 9:15 Page 273
