293
CLUTCH
GEARBOX
DRIVESHAFTS
TIGHTENING TORQUES: BE4/5 GEARBOX
Engines: RFN - RFK - 9HX - 9HY - 9HZ
Tightening torques (m.daN).
(18) Stop guide screw : 1,25 ± 0,2
(19) Speedometer fixing screw : 1,5 ± 0,2
(20) Gearbox support shaft nut : 6,5 ± 0,6
(21) Nuts fixing rubber support :3 ±0,2
(22) Gearbox rubber support shaft :5 ±0,5
(23) Screw M10 fixing the engine/gearbox housing support :6 ±0,5
(24) Screws M10 fixing the engine/gearbox housing support :3 ±0,3
B2CP401C
B2CP400C
