369
BRAKES
VALUES FOR CHECKING AND ADJUSTING THE BRAKING SYSTEM
Rear brake
Engines KFU - NFU- RFJ - RFN - RFK - 9HX - 9HY - 9HZ - RHR
Diameter (mm) 249
Thickness (mm) 9
Rear brake disc Minimum thickness (mm) 7
Difference in maximum
thickness on the same 0,01
circumference (mm)
Maximum run-out (mm) 0,05
Rear brake Thickness (mm) 11
pads Minimum thickness (mm) 3
Vacuum pump pressure
Engine oil temperature Minimum vacuum
Maximum time (in seconds) to attain the minimum
vacuum
80°C ± 5°C
500 mbars 4,5 seconds
800 mbars 18 seconds
