54

ENGINES

SPECIAL FEATURES: TIGHTENING TORQUES

Engine: KFU

B1CP0GYC

B1DP05BC

IMPERATIVE: Respect the tightening sequence.

Cylinder block

(14) Crankshaft bearing cap sealing screw

(25) Crankshaft bearing cap cover screw (21) Flywheel screw
