79

ENGINES

CYLINDER HEAD

Engine: RFJ

B1DP1LPD

Identification of cylinder head gasket

Supplier MEILLOR

A : Timing end

Thickness 0,67 ± 0,04 mm B : Clutch end

C : Engraving zone

D : Marking zone

Multi-layer metallic cylinder head gasket
