91

ENGINES

CYLINDER HEAD

Engine: RFN

Identification of cylinder head gasket

B1DP183D

Nominal

dimension

Repair dimension

2-4-54-5

R1 R2

1,1 1,40,8

Gasket thickness

(mm)

Supplier MEILLOR

Marking zone

"e"

Identification zone

"d"

NOTA : Multilayer metallic gasket.

UK-C4-page048-130-2004 15/11/04 9:23 Page 91
