WS1CI & WS1.25CI Manual
Pa
g
e
3
7
W
ater Meter
, Meter Plug and Mixing V
alve
3
4
5
1
2
6
Drawing No.
Order No.
Description
Quantity
1
V3151
WS1 Nut 1” QC
1
2
V3003*
WS1 Meter
ASY
1
3
V3118-01
WS1 T
urbine ASY
1
4
V3105
O-ring 215
1
5
V3003-01
WS1 Meter Plug
ASY
1
6
V3013
Mixing V
alve
optional
*Order number V3003 includes
V3118-01
WS1 T
urbine
ASY
and V3105 O-ring 215.
35
37
