WS1CI & WS1.25CI Manual Page 7
For DIR Softeners, there are two options for setting the Volume Capacity. The Volume Capacity is automatically calculated if set to AUTO.
Reserve Capacity is automatically estimated based on water usage if AUTO is used. The other option is to set the Volume Capacity to a specifi c
number. If a specifi c number is set, reserve capacity is zero, unless the value is manually set (i.e. the manufacturer intentionally sets the volume
capacity number below the calculated capacity of the system).
The control valve can also be set to regenerate immediately or at the next regeneration time by changing the Regeneration Time Option. There are
three choices for settings:
1. “NORMAL” means regeneration will occur at the preset regeneration time.
2. “on 0” means regeneration will occur when the volume capacity reaches zero.
3. “NORMAL” and “on 0” means the regeneration will occur at the preset regeneration time unless the volume capacity reaches zero. If the
volume capacity reaches zero the regeneration will begin 10 minutes after no water usage.
The user can initiate manual regeneration. The user has the option to request the manual regeneration at the delayed regeneration time or to have
the regeneration occur immediately:
1. Pressing and releasing the REGEN button. “Regen Today” will fl ash on the display and the regeneration will occur at the delayed regeneration
time. The user can cancel the request by pressing and releasing the REGEN button. This method of manually initiating regeneration is not
allowed when the system is set to “on 0”, i.e. to immediately regenerate when the volume capacity reaches zero.
2. Pressing and holding the REGEN button for approximately 3 seconds will immediately start the regeneration. The user cannot cancel this
request, except by resetting the control by pressing NEXT and REGEN buttons simultaneously for 3 seconds.
The WS1CI & WS1.25CI control valves consist of the following components:
1. Drive Assembly 6. Drain Line Flow Control and Fitting Assembly
2. Drive Cap Assembly, Main Piston and Regenerant Piston 7. Water Meter or Meter Plug
3. Spacer Stack Assembly 8. Mixing Valve (optional)
4. Injector Cap, Screen, Injector Plug and Injector 9. Installation Fitting Assemblies
5. Refi ll Flow Control Assembly or Refi ll Port Plug 10. Bypass Valve (optional)
Note: The WS1CI & WS1.25CI share many of the same components. Refer to Figure 6 for control valve identifi cation.
2
See Installer Display Settings, OEM Softener System Setup and OEM Filter System Setup for explanations of Day Override and Volume
Capacity.
3
Day Override and Volume Capacity can not both be set to “oFF” at the same time.
The control valve with a water meter can be set for Demand Initiated Regeneration (DIR) only, Time Clock operation only or DIR and Time Clock
which ever comes fi rst, depending upon what settings are selected for Day Override and Volume Capacity.
2
See Table 5.
If a control valve does not contain a meter, the valve can only act as a time clock, and day override should be set to any number and volume
capacity should be set to off.
Table 4
Regeneration Cycles Filtering
WS1CI & WS1.25CI
Downfl ow Regenerant Refi ll
After Rinse
WS1CI & WS1.25CI
Downfl ow Regenerant
Prefi ll
WS1CI & WS1.25CI
No Regenerant
1
st
Cycle: Backwash
2
nd
Cycle: dn Brine
3
rd
Cycle: Backwash
4
th
Cycle: Rinse
5
th
Cycle: Fill
6
th
Cycle: End
1
st
Cycle: Fill
2
nd
Cycle: Filtering
3
rd
Cycle: Backwash
4
th
Cycle: dn Brine
5
th
Cycle: Backwash
6
th
Cycle: Rinse
7
th
Cycle: End
1
st
Cycle: Backwash
2
nd
Cycle: Rinse
3
rd
Cycle: Backwash
4
th
Cycle: Rinse
5
th
Cycle: End
DIR
Time
Clock
Reserve Capacity Softener
Filter Settings
3
Regenerant
Backwash
Only
Day
Override
Volume
Capacity
Yes Automatically calculated Yes Off Auto
Yes
If desired enter a value less
than estimated capacity
Yes Yes Yes Off
Any
Number
Yes Yes Automatically calculated Yes
Any
Number
Auto
Yes Yes
If desired enter a value less
than estimated capacity
Yes Yes Yes
Any
Number
Any
Number
Yes None Yes Yes Yes
Any
Number
Off
Table 5
