Clack WS1CI User Manual

WS1CI & WS1.25CI Manual Page 5
Table 2 contains a summary of specifi cations for the control valve and bypass valve.
Table 1
Specifi cations which must be included in OEM’s Manual
Table 2
Quick Reference Specifi cations
Minimum/Maximum Operating Pressures 138 kPa (20 psi)/(1.4 bar) - 862 kPa (125 psi)/(8.6 bar)
Minimum/Maximum Operating Temperatures 4°C (40°F) - 43°C (110°F)
AC Adapter:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
U.S. International
120 V AC 230V AC
60 Hz 50 Hz
12 V AC 12 V AC
500 mA 500 mA
No user serviceable parts are on the PC board, the motor, or the AC adapter. The means of
disconnection from the main power supply is by unplugging the AC adapter from the wall.
Service fl ow rate 1" (includes bypass and meter) 102.2 lpm (27 gpm) @103 kPa (15 psig) drop
Backwash fl ow rate 1" (includes bypass) 102.2 lpm (27 gpm) @172 kPa (25 psig) drop
Service fl ow rate 1.25" (includes meter) 128.7 lpm (34 gpm) @103 kPa (15 psig) drop
Service fl ow rate 1.25" (includes bypass and meter) 121.1 lpm (32 gpm) @103 kPa (15 psig) drop
Backwash fl ow rate 1.25" 121.1 lpm (32 gpm) @172 kPa (25 psig) drop
Backwash fl ow rate 1.25" (includes bypass) 113.5 lpm (30 gpm) @172 kPa (25 psig) drop
Minimum/Maximum Operating Pressures 138 kPa (20 psi) - 862 kPa (125 psi)
Minimum/Maximum Operating Temperatures 4°C (40°F) - 43°C (110°F)
AC Adapter:
Supply Voltage
Supply Frequency
Output Voltage
Output Current
U.S. International
120 V AC 230V AC
60 Hz 50 Hz
12 V AC 12 V AC
500 mA 500 mA
Regenerant Refi ll Rate 1.9 lpm (0.5 gpm)
Injectors See Injector Graphs
Drain Line Flow Controls See Table 7
Inlet / Outlet Fitting Options (a) 1” NPT elbow which has a unique drill out feature to
allow a ¼” NPT connection to the inlet and/or outlet
(b) ¾” & 1” PVC solvent weld fi tting
(c) 1” straight brass sweat fi tting
(d) ¾” straight brass sweat fi tting
(e) 1” plastic male NPT fi tting
(f) 1 ¼” plastic male NPT fi tting
(g) 1” plastic male BSPT fi tting
(h) 1 ¼” plastic male BSPT fi tting
Distributor Tube Opening WS1CI Valve 1.05” outside diameter (¾” NPS)
Distributor Tube Opening WS1.25CI Valve
1.32” outside diameter (1” NPS)
32 mm outside diameter
Tank Thread 2 ½” - 8 NPSM
Control Valve Weight 4.5 lbs. 2.0 kg
PC Board Memory Nonvolatile EEPROM
(electrically erasable programmable read only memory)
Compatible with regenerants/chemicals Sodium chloride, potassium chloride, potassium
permanganate, sodium bisulfi te, chlorine and chloramines
