Clarion WXZ468RMP Service Manual

- 11 -
WXZ468RMP
ELECTRICAL PARTS LIST
Switch PWB(B1) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
C701 168-1042-78 16V 0.1uF
C702 168-1022-55 1000pF K
C703 042-0423-97 16V 10uF
C704 168-1032-55 0.01uF K
C705 168-1042-78 16V 0.1uF
C706 168-1022-55 1000pF K
C708 168-1042-78 16V 0.1uF
C709 043-0318-90 5600pF
C710 043-0318-90 5600pF
D705 001-7040-91 NSCW100-T
D706 001-7040-91 NSCW100-T
D707 001-7040-91 NSCW100-T
D708 001-7040-91 NSCW100-T
D709 001-7040-91 NSCW100-T
D710 001-7095-90 HUB1105W-12-RR
D711 001-7040-91 NSCW100-T
D712 001-7040-91 NSCW100-T
D713 001-7043-90 CL-170FG F-GREEN
D714 001-7043-90 CL-170FG F-GREEN
D715 001-7062-90 RBR1111C
D716 001-7062-90 RBR1111C
D717 001-7062-90 RBR1111C
D718 001-7062-90 RBR1111C
D719 001-7062-90 RBR1111C
D720 001-7062-90 RBR1111C
D721 001-0516-90 MA111
D722 001-0516-90 MA111
D751 001-4301-32 HZU 5.6B2
D752 001-4301-32 HZU 5.6B2
D753 001-4301-32 HZU 5.6B2
D754 001-4301-32 HZU 5.6B2
D755 001-4301-32 HZU 5.6B2
D756 001-4301-32 HZU 5.6B2
D757 001-4301-32 HZU 5.6B2
D758 001-4301-32 HZU 5.6B2
D759 001-4301-32 HZU 5.6B2
D766 001-4301-32 HZU 5.6B2
D767 001-4301-21 HZU3.9B2
D768 001-4301-32 HZU 5.6B2
D769 001-4301-32 HZU 5.6B2
D770 001-4301-32 HZU 5.6B2
D771 001-4301-32 HZU 5.6B2
FL701 379-4056-28 VFD
IC701 051-6642-08 LC75700T
IR701 060-4017-90 IR RECEIVER
J701 074-3010-60 10P
J702 074-3010-72 22P
L701 010-3406-66 NLV25 22uH J
Q794 125-2199-96 KRC106S
Q795 125-2199-96 KRC106S
Q796 125-2199-96 KRC106S
Q797 125-2199-96 KRC106S
Q798 125-2199-96 KRC106S
Q799 125-2199-96 KRC106S
R710 119-1021-15 1/10W 1k ohm
R711 119-3931-15 1/10W 39k ohm
R712 119-2211-15 1/10W 220 ohm
R713 119-2211-15 1/10W 220 ohm
R714 119-2211-15 1/10W 220 ohm
R715 119-2211-15 1/10W 220 ohm
R716 119-2211-15 1/10W 220 ohm
R717 119-2211-15 1/10W 220 ohm
R718 119-2711-15 1/10W 270 ohm
R719 119-2711-15 1/10W 270 ohm
R720 119-2711-15 1/10W 270 ohm
R721 119-2711-15 1/10W 270 ohm
R722 119-8211-15 1/10W 820 ohm
R723 119-5611-15 1/10W 560 ohm
R724 119-8211-15 1/10W 820 ohm
R725 119-2711-15 1/10W 270 ohm
R726 119-3311-15 1/10W 330 ohm
R727 119-3311-15 1/10W 330 ohm
R728 119-1011-15 1/10W 100 ohm
R729 119-1021-15 1/10W 1k ohm
R730 119-1021-15 1/10W 1k ohm
R736 119-3331-15 1/10W 33k ohm
R737 119-2721-15 1/10W 2.7k ohm
R738 119-1201-15 1/10W 12 ohm
R739 119-1201-15 1/10W 12 ohm
R740 119-3311-15 1/10W 330 ohm
R741 119-3311-15 1/10W 330 ohm
R742 119-3311-15 1/10W 330 ohm
R743 119-3311-15 1/10W 330 ohm
R744 119-1031-15 1/10W 10k ohm
R745 119-3311-15 1/10W 330 ohm
R746 119-3311-15 1/10W 330 ohm
R747 119-3311-15 1/10W 330 ohm
S701 013-6312-50 SKRP-ABE-010
S702 013-6312-50 SKRP-ABE-010
S703 013-6312-50 SKRP-ABE-010
S704 013-6312-50 SKRP-ABE-010
S705 013-6312-50 SKRP-ABE-010
S706 013-6312-50 SKRP-ABE-010
S707 013-6312-50 SKRP-ABE-010
S708 013-6312-50 SKRP-ABE-010
S709 013-6312-50 SKRP-ABE-010
S710 013-6312-50 SKRP-ABE-010
S711 013-6312-50 SKRP-ABE-010
S712 013-6312-50 SKRP-ABE-010
S713 013-6312-50 SKRP-ABE-010
S714 013-6312-50 SKRP-ABE-010
S715 013-6312-50 SKRP-ABE-010
S716 013-6312-50 SKRP-ABE-010
S717 013-6312-50 SKRP-ABE-010
S718 013-6312-50 SKRP-ABE-010
S719 013-6312-50 SKRP-ABE-010
VR701 016-9900-84 VR W/SHAFT
VR702 016-9900-94 VR W/SHAFT
VR703 016-9900-94 VR W/SHAFT
VR704 016-9901-00 VR W/SHAFT
PWB 039-2797-01 PWB(WITHOUT
COMPONENT)
Main PWB(B2) section
REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION REF No. PART No. DESCRIPTION
ANT1 092-4000-51 ANTENNA RECEPT
BL1 880-2150A CCC-TUNER
C1 166-1511-50 150pF CH
C2 187-4763-35 16V 47uF
C3 168-2232-55 0.022uF K
C4 187-4763-35 16V 47uF
C5 168-2232-55 0.022uF K
C6 187-4763-35 16V 47uF
C7 168-2232-55 0.022uF K
C8 187-1063-35 16V 10uF
C9 187-1063-35 16V 10uF
C11 187-1063-35 16V 10uF
C12 187-1063-35 16V 10uF
C13 166-2201-50 22pF CH
C15 166-1011-50 100pF CH
C16 168-4732-78 0.047uF K
C25 187-2253-65 50V 2.2uF
C102 178-4742-78 0.47uF
C103 178-4742-78 0.47uF
C104 178-4742-78 0.47uF
C105 178-4742-78 0.47uF
C106 187-1063-35 16V 10uF
C107 187-2253-65 50V 2.2uF
C108 172-1041-15 0.1uF
C109 187-1053-65 50V 1uF
C110 178-4742-78 0.47uF
C116 168-1022-55 1000pF K
C125 168-1022-55 1000pF K
C126 168-1022-55 1000pF K
C127 168-1022-55 1000pF K
C128 168-1022-55 1000pF K
C129 168-1022-55 1000pF K
C130 168-1022-55 1000pF K
C131 168-1022-55 1000pF K
C132 168-1022-55 1000pF K
C205 042-1393-00 35V 100uF
C206 042-1655-00 63V100uF
C207 042-9134-00 63V 47uF
C210 168-1042-78 16V 0.1uF
C211 168-1042-78 16V 0.1uF
C214 189-3383-32 16V 3300uF
C216 168-1042-78 16V 0.1uF
C217 168-1042-78 16V 0.1uF
C218 187-1073-35 16V 100uF
C219 168-1042-78 16V 0.1uF
C220 187-1073-35 16V 100uF
C221 187-1073-35 16V 100uF
C223 168-4732-78 0.047uF K
C224 168-2232-55 0.022uF K
C225 187-4763-35 16V 47uF
C226 168-1042-78 16V 0.1uF
C301 166-1501-50 15pF CH
C302 166-1501-50 15pF CH
C303 168-1032-55 0.01uF K
C304 168-1032-55 0.01uF K
C305 187-4753-55 35V 4.7uF
C306 168-1032-55 0.01uF K
C307 043-0540-02 16V 1uF
C308 043-0540-02 16V 1uF
C309 187-1063-35 16V 10uF
C310 187-1063-35 16V 10uF
C311 187-1063-35 16V 10uF
C312 168-1042-78 16V 0.1uF
C313 042-1631-50 10V 100uF
C314 168-1042-78 16V 0.1uF
C315 187-1063-35 16V 10uF
C316 168-1042-78 16V 0.1uF
C318 187-1063-35 16V 10uF
C319 168-1042-78 16V 0.1uF
C322 168-1042-78 16V 0.1uF
C323 168-1042-78 16V 0.1uF
C324 168-1042-78 16V 0.1uF
C325 168-1022-55 1000pF K
C326 166-1011-50 100pF CH
C327 168-1022-55 1000pF K
C328 166-1011-50 100pF CH
C329 168-1022-55 1000pF K
C330 166-1011-50 100pF CH
C331 042-1631-50 10V 100uF
C332 042-1631-50 10V 100uF
C333 168-1042-78 16V 0.1uF
C340 168-4732-78 0.047uF K
C341 168-4732-78 0.047uF K
C401 168-1042-78 16V 0.1uF
