Page -14- Clarke
®
Operator's Manual -Focus Rider Scrubber
Symbols Used On FOCUS 28 & 34
Brush Up/Down
Squeegee
Up/Down
Solution Flow
Switch
Battery Meter
LCD Display
Button
Horn Button
One Touch
Traverse Speed
On/Off Switch
i-Drive
Directional
Guide
Recovery /
Solution LED
Warning Label
EN
