Clarke Focus - Solution Tank Assembly Parts List

Clarke
®
Operator's Manual - Focus Rider Scrubber Page -75-
Clarke
®
FOCUS Rider Scrubber
Solution Tank Assembly Parts List 6/04
Drawing # 10784A
Ref Part No. Description Qty
1 85811A Screw, 5/16 - 18 x 3/4 Hex Head 8
2 980651 Washer, 5/16 Flat 14
3 61492A Plate, Seat Assembly 1
4 10780A Arm, Control Left 1
5 980645 Washer, 3/8” SAE Flat 18
6 170883 Washer, Lock 3/8” 14
7 962216 Screw, 3/8-16 x 1 1/4 Hex 8
8 61573A Cable, Recovery Tank 1
9 61490A Mount, Seat Assembly 1
10 85395A Screw, 1/4-20 x 1/2 PH 13
11 61489A Plate, Cover 1
12 40728A Display, Battery Charger 1
13 30566A Hose, 5/8” ID X 7/8” OD X 12 1
14 53498A Fitting, ELL Pipe 1
15 30530A Tank, Solution 1
16 193944 Grommet 1
17 10781A Arm, Control Right 1
18 980652 Washer, 5/16 Lock 6
19 61562A Stop, Seat 2
20 81112A Nut, 5/16 - 18 Thin ESNA 4
21 30534A Chair, Asm. 1
22 962086 Screw, 1/4 - 20 x 3/4 Hex Head 4
23 87026A Washer, 1/4 Flat SS 4
24 980657 Washer, Lock 1/4 4
