Operator's Manual - Focus Rider Scrubber Page -69-
Clarke
®
FOCUS Rider Scrubber
Main Frame Assembly Parts List 6/04
Drawing # 10778A
Ref Part No. Description Qty
1 766780 Pin, Hair 1
2 836713 Pin, Clevis 1
3 53886A Actuator, Head Lift 1
4 40889A Horn 1
5 53448A Mount, Cover 2
6 962086 Screw,1/4-20 x 3/4 Hex Head 10
7 980657 Washer, Lock 1/4 12
8 962288 Bolt, 3/8 - 16 x 1 Hex Head 10
9 170883 Washer, 3/8 Lock 22
10 980645 Washer, 3/8 Flat 22
11 53436A Steering, Asm. Power 1
12 61473A Linkage, Rod 4
13 920204 Nut, 3/8 - 24 Hex Jam 8
14 53493A Pin, Quick Release Actuator Btm. 1
15 61482A Weldment, Head Carriage 1
16 818381 Spring, Extension 1
17 962244 Bolt, 3/8 - 16 x .75 Hex 10
18 61475A Clamp, Transaxle 2
19 51609A Bumper, Rear 2
20 962430 Screw, 10 - 32 x 3/8 2
21 81221A Nut, 1/2 - 20 Lug 8
22 61382A Wheel, Anti-Skid 2
23 40868A Transaxle 1
24 61572A Mount, Front Squeegee 1
25 61481A Weldment, Mainframe 1
26 413754 Grip, Sol. Tank Clamp 1
27 85700A Screw, 1/4 - 20 x 1 1
28 980205 Washer, .31 ID x 1.06 OD 2
29 980614 Washer, 1/4 Starlock, Ext 3
30 81104A Nut, 1/4 Nylock 3
31 61302A Strap, Static 1
32 48703A Valve, Electric 1
33 30445A Hose, Solution (Flex) 1
34 722030 Clamp, Hose 2
35 170915 Screw, 1/4 - 20 x 3/4 Hex Head 2
36 50248A Hose Clamp 1
37 962430 Screw, 1/4 - 20 x 1/2 HHCS 2
38 87026A Washer, 1/4 Flat SS 2
39 30558A Pad, Brush Carriage Stop 1
40 30453A Hose, Clear Vinyl 1
41 59614A Valve, Battery Drain 1
