Clarke Focus - Final Assembly Parts List

Clarke
®
Operator's Manual - Focus Rider Scrubber Page -67-
Clarke
®
FOCUS Rider Scrubber
Final Assembly Parts List 9/04
Ref Part No. Description Qty
1 10783A Tank, Recovery (Assembly) 1
2 10784A Tank, Solution (Assembly) 1
3 10782A Plate, Electrical 1
4 10778A Mainframe, Main Asm. 1
5 10779A Wheel, Front Steering 1
6 61548A Arm, Sec. Squeegee Lift 1
7 10694A Squeegee, Secondary 1
8 10697A Assembly, 28” Brush Head 1
9 10149A Assembly, Squeegee 32” 1
10 10787A Arm, Rear Squeegee Lift 1
11 40704A Pack, Battery 370 AH 1
12 60256A Bracket, Pivot 1
13 53491A Pin, Quick Release 1
NI 40895A Positive Cable 1
NI 40896A Negative Cable 1
NI 40882A Cable Fuse 1
NI 40726A Fuse, 200 Amp 1
NI 41217A Cable, Series 4
NI= Not illustrated
