Clarke Focus - Recovery Tank Assembly Parts List

Clarke
®
Operator's Manual - Focus Rider Scrubber Page -73-
Ref Part No. Description Qty
1 52206A Chain, Drain Asm. 1
2 962957 Screw, 10 -16 x 1/2 Self Tab 2
3 30226A Plug, Drain 1
4 40002A Switch, Float Electrical 1
5 58069A Screen, Vac Filter 1
6 30581A Lid, Recovery Tank 1
7 30582A Gasket, Rec. Tank Lid 1
8 39339B Tube, Stand 90
o
1
9 837304 O-Ring, Retainer 2
10 82100A Locknut, 1/2 1
11 30531A Tank, Recovery 1
12 920797 Nut, Drain Valve 1
13 30132A Tube, Stand Straight 1
14 643418 Gasket, Vac Unit 1
15 58533A Spacer, Vac Motor 3
16 45019A Motor, Vac` 1
17 41809A Contact, Housing Connector 2
18 43401A Housing, Connector 2
19 85728A Screw, 1/4 - 20 x 4 Hex HD 3
20 61565A Panel, Recovery Vac Motor 1
21 85395A Screw, 1/4 - 20 x 1/2 PH 8
22 61478A Retainer, Lower Hose 1
23 30561A Coupler, Hose 1
24 61573A Cable, Recovery Tank 1
25 61498A Retainer, Mid Hose 1
26 61477A Retainer, Upper Hose 1
27 872010 Clamp, Hose 2
28 30550A Hose, Recovery 1
29* 30559A Gasket, Clean Out 1
30* 61566A Clean-Out, Drain 1
31* 53477A Knob, 1/4 - 20 Clamp 4
32 30225A Body, Drain Valve 1
33* 40876A Sensor, Water Level 1
34 52560A O-Ring, .103 x 7.99 ID 1
35 30227A Housing, Drain 1
NI 30568A Hose, Squeegee 1
NI 30567A Hose, Vac 1
NI 30448A Hose, Exhaust 1
NOTE: * Optional accessories
NI = Not illustrated
Clarke
®
FOCUS Rider Scrubber
Recovery Tank Assembly Parts List 6/04
Drawing # 10783A
