17
This series product max supports 32-channel standard definition video/high definition non-real-time
video and the transmission rate is 1mbps per channel. It can also max supports 4-channel high
definition video and the transmission rate is 8mbps. The delay time of each channel is below 500ms.
Model System Performance
4-ch series Max support 4-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
8-ch series Max support 8-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
16-ch series Max support 16-channel video.
Total resources:400/480fps@D1,200/240fps@720P.100/120@1080P.
32-ch series Max support 32-channel standard definition video.
Support 8-channel 1080p/5mbps (extra stream D1/1mbps), 16-channel
720p/2mbps (extra CIF/640kbps), 32-channel D1/1mbps.
This series product supports the IPC from many popular manufactures such as Sony, Hitachi,
dynacolor, Axis, Samsung, arecont, Dahua, onvif and custom type. You can just input URL address,
user name, and password to login the front-end device.
In the following interface, you can see there are three connection modes: auto, TCP (default), UDP.
Figure 2-17
2.6.4 Short-cut Menu
In the preview interface, for the channel of no IPC connection, you can click the icon “+” in the centre of
the interface to quickly go to the Remote Device interface. See Figure 2-18 and Figure 2-19.
