6WUXFWXUH

&RPSRQHQWV
You can refer to the following figure for multiple-function combination cable information. See Figure
1-1
.
Figure 1-1 Multiple-function combination cable
Please refer to the following sheet for detailed information.
No.
Port
Name
Connector
Note
4
LAN
Network
port
Ethernet
To connect to standard
Ethernet.
5
DC12V
DC 12V
power
To connect to
DC12V
power
supply.

)UDPHZRUNDQG'LPHQVLRQ
Component
Component Name
Component 1
Device lens
Component 2
Dome body
Component 3
Dome enclosure
