Clek Foonf 2017 - Page 19

16
Figure 3
Figure 4
P The tops of the child’s ears must be below the
top of the car seat’s Headrest, as shown in
Figure 3.
NOTE: If the tops of the child’s ears are
above the top of this car seat’s Headrest in
the highest adjustment position, your child is
too large for this car seat.
P The Shoulder Harness Straps must be through
Shoulder Harness Slots at or above and
closest to the child’s shoulders, as shown in
Figure 4, with the following exceptions:
– If installing without the Top Tether,
choose one of the top two (2) sets of
Shoulder Harness Slots at or just above
and closest to the shoulders of your child
– If installing without the Top Tether,
and with children under 40lb (18.1 kg),
the Shoulder Harness Straps must be
adjusted to the shorter Shoulder Harness
Webbing length.
NOTE: If the child’s shoulders are above the
highest set of Shoulder Harness Slots in the
car seat’s seat back, your child is too large
for this car seat.
