Attention:
Always carry out all work with the drive and motor switched off!
Remove ignition key!
Secure the tractor and machine against unintentional movements (e.g. rolling away, lowering,
etc.).
Observe the relevant accident prevention regulations and all other information given in the
operating instructions!
5.1 Preparing the machine and the tractor
The RADIUS SL is mounted on the bracket of your frame or lifter. If you are not equipped with a suitable bracket,
please contact your dealer, who will be able to supply and install a bracket for your application.
The hydraulic supply is provided via the single acting distributor of your tractor. Your RADIUS SL is controlled
either via the tractor control system or via the CLEMENS C.CONTROL system, depending on your tractor's
configuration and equipment.
The hydraulic lines must be bundled and fastened in such a way that the lift frame's range of movement is not
restricted and they cannot be crushed or caught and torn off by rotating parts (PTOs, tires, etc.). They must also
be installed at a sufficient distance from heat sources.
The retrofitting of optional parts must be carried out by a specialist workshop.
