RADIUS SL 860 07.2019 en 32
10.6 Swivel cylinder
Figure 27 Spare parts Swivel cylinder
The following parts are the same for both piston rod diameters:
Conical lubricating nipple
High pressure hose with pressed fittings
The following parts must be used for piston rod diameter of 25 mm (1”):
The following parts must be used for piston rod diameter of 30 mm (1.2”):
Note:
Spare parts for the Ø25 (1”) piston rod are indicated in red bold type.
Spare parts for the Ø30 (1.2”) piston rod are indicated in green bold type.
Spare parts for both piston diameters are shown in normal font.
Note:
You can easily determine which cylinder your device is equipped with. The cylinders with a
piston rod diameter of 25 mm are painted red ex works, the cylinders with a piston rod diameter
of 30 mm are painted anthracite ex works.
