The machine/implement must be lubricated regularly according to the lubrication schedule. Any large
accumulations of grease which may become loose during work or transport must be removed. Cloths soiled with
grease must then be stored in suitable containers until they are cleaned or disposed of.
Lubricate every 10 working hours at the points marked "X". After cleaning, the lubrication points should also be
lubricated. This increases the service life of your machine/attachment.
If the sensor unit is no longer smooth-running after lubrication, too much grease has been pressed in.
This can be remedied by pressing the sensor unit several times by hand.
Figure 20 Lubrication schedule
