RADIUS SL 860 07.2019 en 53
A = Pressure hose
Item no.
Specification
Remark
Quantity
Order no.
1
Pressure hose 4000 mm (157.5”)
“L“ = length in mm
1
CW700.065100
2
Pressed fitting
1
CW710.004500
3
Pressed fitting
1
CW710.004600
B = Return oil hose
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose 4000 mm (157.5”)
“L“ = length in mm
1
CW700.065000
2
Pressed fitting
2
CW710.004400
C = Bridge hose
Item no.
Specification
Remark
Quantity
Order no.
1
Hydraulic hose 500 mm (19.7”)
“L“ = length in mm
1
CW700.001300
2
Pressed fitting
2
CW710.004200
Note:
When ordering hydraulic hoses, measure the length "L" (including pressed fittings) and indicate
in mm (Conversion aid: 1” = 25.4 mm).
1
2
3
“L“ = length in mm incl. pressed fittings
1
2
2
“L“ = length in mm incl. pressed fittings
