Clevo D400E - External Locator - Front & Left Side Views

Introduction
1 - 8 External Locator - Front & Left Side Views
1.Introduction
External Locator - Front & Left Side Views
Figure 3
Front View
1. LCD Latches
2. Mini IEEE 1394
Port
3. S/P DIF Out Port
4. Microphone Jack
5. Headphone Jack
6. Infrared
Transceiver
7. Wireless Device
ON/OFF Switch
8. Built-In Speakers
4 5
6 7
1
2
1
3
8 8
Figure 4
Left Side View
1. CD-ROM Bezel or
CD-ROM Device
2. USB 2.0/1.1 Port
3. Floppy Disk Drive
4. PC Card/ PCMCIA
Slot
5. PC Card/PCMCIA
Slot Eject Buttons
3
4
1
5
2
