Disassembly
2 - 12 Removing the CD Device
2.Disassembly
Removing the CD Device
The easy changeable CD device may be upgraded or changed.
1. Turn off the computer, remove the battery (page 2 - 8) and turn it over.
2. Remove screws - (Figure 5a) from the memory socket cover
.
3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon-
nect it).
1 6
7 8
Figure 5
Memory Socket
Cover Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
1
2
54
3
6
8
a.
7
b.
7. Socket Cover
•6 Screws
To Next Page
