Disassembly
Removing the CD Device 2 - 13
2.Disassembly
4. Use a screwdriver to carefully push the CD device assembly out of the computer at point .
5. Insert the new device and carefully slide it into the computer (the device only fits one way. DO NOT FORCE IT; The
screw holes should line up.
6. Replace the memory socket cover (be careful with the fan cable) and the 6 screws (see page 2 - 12 ).
7. Restart the computer to allow it to automatically detect the new device.
1 2
2
1
Figure 6
CD Device Removal
Push the CD device out
off the computer at point
2.
1. CD Device
To Next Page
