Clevo D400E - Removing the Wireless LAN Module

Disassembly
Removing the Wireless LAN Module 2 - 15
2.Disassembly
Removing the Wireless LAN Module
1. Turn off the computer, remove the battery (page 2 - 8) and turn it over.
2. Remove screws - from the memory socket cover
.
3. Carefully lift up the memory socket cover (a fan cable is still attached to the mainboard and you can discon-
nect it).
4. Remove screws
- (Figure 8c), and carefully disconnect cables & .
5. Lift the Wireless LAN module
(Figure 8d) off the computer.
1 6
7 8
Figure 8
Wireless LAN
Module Removal
a. Remove the screws.
b. Carefully lift the cover off
the computer.
9 10 11 12
13

Antenna Cable
Connection
When re-inserting a
Wireless LAN module,
make sure the antenna
cable connects to the
connector J1 which is
indicated as point 12
in Figure 8c.
1
2
54
3
6
8
a.
7
b.
9
10
12
11
c. d.
13

7. Socket Cover
13. WLAN Module
.
•8 Screws
