Introduction
Specifications 1 - 3
1.Introduction
Keyboard
Full-size White-LED Illuminated Keyboard (with numeric
keypad)
Or
(Factory Option) Full Color Illuminated Full-size Keyboard
(with numeric keypad)
Pointing Device
Built-in Touchpad
Interface
One USB 3.1 Gen 2 Type-C Port*
*The maximum amount of current supplied by USB Type-C
ports is 500mA (USB 2.0)/900mA (USB 3.1).
Two USB USB 3.1 Gen 2 Type-A Ports
One USB 2.0 Port
One HDMI-Out Port
Two Mini DisplayPorts 1.3
One Headphone-Out Jack
One Microphone-In Jack
One RJ-45 LAN Jack
One DC-in Jack
Card Reader
Embedded Multi-In-1 Card Reader
MMC (MultiMedia Card) / RS MMC
SD (Secure Digital) / Mini SD / SDHC/ SDXC
M.2 Slots
Slot 1 for Combo WLAN and Bluetooth Module
Slot 2 for SATA or PCIe Gen3 x4 SSD
Slot 3 for PCIe Gen3 x4 SSD
Communication
Built-In 10/100/1000Mb Base-TX Ethernet LAN
1.0M HD PC Camera Module
WLAN/ Bluetooth M.2 Modules:
(Factory Option) Intel® Dual Band Wireless-AC 9260 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9560 Wire-
less LAN (802.11ac) + Bluetooth
(Factory Option) Intel® Dual Band Wireless-AC 9462 Wire-
less LAN (802.11ac) + Bluetooth
Environmental Spec
Temperature
Operating: 5
°C - 35°C
Non-Operating: -20°C - 60°C
Relative Humidity
Operating: 20% - 80%
Non-Operating: 10% - 90%
Power
Full Range AC/DC Adapter
AC Input: 100 - 240V, 50 - 60Hz
DC Output: 19V, 7.89A (150W)
(Factory Option) Built-in 6 Cell Battery Pack, 47WH
Dimensions & Weight
NB50TK1: 378mm (w) * 250mm (d) * 29.8mm (h)
NB55TK1: 378mm (w) * 250mm (d) * 29.6mm (h)
2.3kg (Barebone with 47WH Battery)
