Upgrading The Computer
6 - 14 Upgrading the Hard Disk Drive(s)
6
Removing the Hard Disk from the Secondary HDD Bay (Model A/B)
Note that the secondary hard disk module is used to replace the optical device mod-
ule (CD/DVD) in Model A & B computers.
1. Turn the computer off, remove the AC/DC adapter, turn it over and remove the bat-
tery.
2. Locate the hard disk bay cover and remove screws &
.
3. Remove the hard disk bay cover .
4. Remove the screw at point , and use a screwdriver to carefully push out the
secondary HDD module at point .
