Clevo P150e

Upgrading The Computer
Upgrading the Hard Disk Drive(s) 6 - 15
6
5. When the module is removed turn it over to access the rear.
6. Remove screws - from the secondary HDD module assembly.
7. Remove the hard disk from the module caddy .
8. Reverse the process to install a new hard disk.
Figure 6 - 13
Removing the
Secondary HDD
from the Module
Caddy
(Models A/B)
6
9
10
11
8
6
7
9
10 11
