Advanced M52 Microprocessor User's Guide
ADVANCED M52UMCT2019 COLOR
30
Settings Summary
The following tables summarize the settings in each page:
*Display changes to °F when Temp Units on Page 3 settings is set to °F
*Display changes to °F when Temp Units on Page 3 settings is set to °F
Page 1 : Readings 1
Description Range Default Units
Software version - - -
Co-Work ID 1-16 1 -
Co-Work Total 1-16 1 -
*CW EWT 1 0-45 - °C
*CW LWT 1 0-45 - °C
*CW EWT 2 0-45 - °C
*CW LWT 2 0-45 - °C
*Temp. Return Air 0-50 - °C
*Temp. Supply Air 0-50 - °C
Hum. Return Air 0-99.9 - % RH
Hum. Supply Air 0-99.9 - % RH
*TempFilterDrierA1 0-45 - °C
*Temp.FilterDrierB1 0-45 - °C
*Temp.FilterDrierA2 0-45 - °C
*Temp.FilterDrierB1 0-45 - °C
*Temp. EGT/Ambient 0-45 - °C
Air Pressure 0-9.9 - Ps
Suction Pressure1 0-300 - Ps
Discharge Pressure1 15-515 - Ps
Suction Pressure2 0-300 - Ps
Discharge Pressure2 15-515 - Ps
Voltage 50-130 - %
Page 2 : Readings 2
Description Range Default Units
EXT1 Software ver - - -
EXT2 Software ver - - -
*Suction Temp 1 0-30 - °C
*Suction Temp 2 0-30 - °C
Fan runtime 0-65535 - hours
Comp 1 runtime 0-65535 - hours
Comp 2 runtime 0-65535 - hours
Heater 1 runtime 0-65535 - hours
Heater 2 runtime 0-65535 - hours
Humid runtime 0-65535 - hours
Cooling runtime 0-65535 - hours
