Page 15
DOMESTIC HOT WATER
A different program can be combined to each day of the week
• select the day of the week to be programmed:
the selected day is highlighted in “grey”.
• select a program among the 7 available;
the saved program can be removed;
a new program can be created
• modify the program using buttons
Programming example:
Day: Friday
Program: Circulation program 1
Operation Profile:
Confirm the modification
start
time
end time mode
set point
(previous page)
01 05 Maintenance ref. 8
06 08 Recharge and recirculation ref. 7 + ref. 11
09 11 Maintenance ref. 8
12 14
Maintenance and
recirculation
ref. 8 + ref. 11
15 17 Maintenance ref. 8
18 20 Recharge and recirculation ref. 7 + ref. 11
21 22 Maintenance ref. 8
23 00 Recharge
ref. 7
To Next Page
