Page 46
SYSTEM COMPONENT CONFIGURATION
Radiant area module: configuration of the channels
Modbus Parameter Value Description
1001 02 (A)
0 = Disabled
1 = Thermoreg. 1 G.- HID-T3
2 = Thermoreg. 2 G. - HID-T3
5 = Thermostat Module - HID-T2; HID-Ti2
EnChannel1:
Type of function associated to channel 1
1002 03 (A) As EnChannel1
EnChannel2:
Type of function associated to channel 2
1003 04 (A) As EnChannel1
EnChannel3:
Type of function associated to channel 3
1004 05 (A) As EnChannel1
EnChannel4:
Type of function associated to channel 4
1005 06 (A) As EnChannel1
EnChannel5:
Type of function associated to channel 5
1006 07 (A) As EnChannel1
EnChannel6:
Type of function associated to channel 6
1054 55 (A)
0 = Summer only
1 = Winter only
2 = Summer / Winter
UseMode1: Use type of channel 1
1055 56 (A) As UseMode1 UseMode2: Use type of channel 2
1056 57 (A) As UseMode1 UseMode3: Use type of channel 3
1057 58 (A) As UseMode1 UseMode4: Use type of channel 4
1058 59 (A) As UseMode1 UseMode5: Use type of channel 5
1059 60 (A) As UseMode1
UseMode6: Use type of channel 6
1030 31 (A) 3
Delay of the dew alarm signal (E07), set at 15 minutes to prevent
delayed alarm signals, due to the deactivation of the compressor, once
the set has been reached.
1031 32 (A) 0.0
It is an offset on the dew point, normally it is set at -2C°, considering
that between the temperature of both the panels and surface there is a
difference and on the latter, condensation is not formed on the panels.
This allows working with lower water temperatures at the dew point,
enhancing the cooling capacities.
1069 870 (A) 20C°
Dew point limit exceeded, whose channel is excluded automatically
from the calculation, in order to not affect the water temperature inside
the entire system and the head closes.
1070 71 (B)
0 = Clivet
1 = Modbus KBlue
If thermostat model =1 (Modbus KBlue thermostats) the parameters
from P02 to P07 cannot be set at 5 or 6.
1071 72 (B)
0 = Temperature + RH
1 = Temperature only
2 = RH only
ThermostatCh1
Only if thermostat=1
1072 73 (B) As TermostatCh1
ThermostatCh2
Only if thermostat=1
1073 74 (B) As TermostatCh1
ThermostatCh3
Only if thermostat=1
1074 75 (B) As TermostatCh1
ThermostatCh4
Only if thermostat=1
1075 76 (B) As TermostatCh1
ThermostatCh5
Only if thermostat=1
1076 77 (B) As TermostatCh1
ThermostatCh6
Only if thermostat=1
6 = Electromechanical thermostat
Electromechanical thermostat (connected between "-" and "GND";
closed = active call; No par.71 = 1)
A: parameters set by the AUTOCONFIGURATION function
B: should always be set only with thermostats HID-TI4 and HID-UR (P71 = 1)
