14
About R-290 refrigerant
Ground installation in a corner
B
C
D
A
A
A
mm 1000
C
mm 500
B
mm 300
D
mm 2300
Suspended installation
B
A
A
A
A
A
mm 1000
B
mm 300
The safety area is extended under the unit down to the
ground.
Installation suspended in a corner
B
C
D
A
A
A
mm 1000
C
mm 500
B
mm 300
D
mm 2300
The safety area is extended under the unit down to the
ground.
