18
Description of the system
3.3 Technical data
For optimum performance use the unit in the following ambient temperature ranges.
Models 2.1 www8.1 cooling mode -5°C to 43°C
Models 9.1 ~14.1 cooling mode -5°C to 46°C
Heating mode -25°C to 35°C
DHW production -25°C to 43°C
Keep the measurement guidelines in mind:
Maximum height dierence between the domestic hot water tank and the unit 3m
Maximum permissible distance between the unit and...
Domestic hot water tank 10m
3-way valve 10m
Additional/backup electric heater - boiler 10m
W
CAUTION
In the case of larger distances, contact the supplier for information on possible risks and suggestions to
limit them.
W
CAUTION
If the unit is far away from the DHW storage tank, measure the connection pipes accordingly and check
that they are properly insulated.
3.3.1 Maximum temperatures of components not supplied by CLIVET
System 75°C
DHW 95°C
