Electrical connections
Double zone system
External pump - Secondary circuit pump P_o (zone 1)
Type2 control signal
P_o
SV2 2-way valve
Enabling and configuration on HMI
SV2
Double zone mixed system
Tw2
I
SV3
Zone 2 mixing pump - Pump P_c
Type2 control signal
P_c
3-way valve SV3
Type2 control signal
SV3
Room thermostat
Enabling and configuration on HMI
RT
