7 - CONTROL
Cmd Local state
OFF
ECO
ON
Pmp ON
Cmd Local mode
Cool
Heat
not used
Unit Stata
General
Circuit
Circuit 1 *
Thermostatic
Circuit 1 *
Recovery
Circuit 1 *
Hydronic
Hydronic stata
Master Slave
Stati Master Slave
Parameters Unit
SetPoint
Scheduler Scheduler
User settings Date and hour
Language selection
7.3 MAIN MENU
Main index
Cmd Local state On
Cmd Local mode Cool
Unit stata
Unit parameters
Scheduler
Select
Confirm
Main index
Cmd Local state On
Cmd Local mode Cool
Unit stata
Unit parameters
Scheduler
Select
Local state
ECO : recurrent pump ON-OFF;
compressors keep water system at setpoint
ECO
Pmp ON : pump ON, compressors OFF
Unit Stata
Input, output functioning variables.
See next pages tables
* Circuits number dipend on unit's series .
The menu is repeated for each refrigerant circuit (circuit:
circuit1, circuit2,.....;thermostatic: circuit1, circuit2,....)
Menu Setpoint
P0001:SetPoint Cool - Cooling
P0002:SetPoint Heat - heating NOT USED
P0003:2°SetPoint Cool - enable by remote switch
P0004:2°SetPoint Heat NOT USED
P0005:SetPoint ECOCool
P0006:SetPoint ECOHeat NOT USED
P0007:SetPointRec - recovery
Schedule
See next page.
