CLIVET WSAT-XEE Series User Manual

36
7 - CONTROL
GENERAL STATA E CENTRAL MODULE
code description description
AI-687
Temp.In H2O
userside_B1
Inlet water temperature utility side
AI-687
Temp.Out H2O
userside_B1
Outlet water temperature utility side
AI-687 Ext.Air temp_B3 External air temperature
AI-687 S.DemandLimit_X1 Demand limit signal
AI-687 S.WaterReset_X2 Water reset signal
AI-687 RHExt_X3 External humidity
AI-687 El.CabinetTemp_X4 Cabinet temperature
AO-687 %FreeCooling _X5 % value external freecooling signal
DI-687 Sel.SetPoint_DU2 2nd setpoin status : 0=1°set 1=2°Set
DI-687 SystemPressure_DU1 System pressure probe status: 0=OK 1=Fault
DI-687 FlowUser_X8 Flow switch utility side status: 0=OK 1=Fault
DI-687 RemON-OFF_X7 Unit status: 0=OFF 1=On
DI-687 Heat/CoolRem_X6 Unit mode: 0=Heat 1=Cool
DI-687 PhaseMonitor_DL1 Phase monitor : 0=OK 1=Fault
DI-687 OvlP1Util_D2 Pump1 thermal protection utility side: 0=OK 1=Fault
DI-687 OvlP2Util_D1 Pump2 thermal protection utility side: 0=OK 1=Fault
DI-687 OvlP3Util_DL2 Pump3 thermal protection utility side: 0=OK 1=Fault
DO-687 El.CabinetFAN_DO1 Cabinet fan : 0=Off 1=On
DO-687 El.CabinetHEAT_DO2 Cabinet heating : 0=Off 1=On
DO-687 UnitMode_Q1
Unit mode digital output (N.O. open=Cool N.O. closed=Heat):
0=Cool 1=Heat
DO-687 Cumul.Alarm_Q2 Cumulative alarm (N.O. open=All OFF N.O. closed=All ON): 0=Off 1=On
DO-687 CmdP1User_Q3 Command pump 1 utility side : 0=Off 1=On
DO-687 CmdP2User_Q4 Command pump 2 utility side : 0=Off 1=On
DO-687 CmdP3User_Q5 Command pump 3 utility side : 0=Off 1=On
DO-687 OpenYV FC_Q7 Free-cooling opening command closed FC = ON: 0=Off 1=On
DO-687 CloseYV FC_Q8 Free-cooling closing command closed FC = OFF: 0=Off 1=On
DO-687 AntifreezeHeater_Q6 Antifreeze heater : 0=Off 1=On
S0001 StartsP1User Starts pump1 utility side
S0002 StartsP2User Starts pump2 utility side
S0003 StartsP3User Starts pump3 utility side
S0004 Pump1 running hours Hours pump1 utility side
S0005 Pump2 running hours Hours pump2 utility side
S0006 Pump3 running hours Hours pump3 utility side
S0007 Antifreeze heat. Antifreeze heater 0=Off 1=On
S0008
pump in antifreeze
alarm
Pump ON by antifreeze alarm: 0=Off 1=On
S0009 recovery Recovery 0=Off 1=On
S0010 ActualSptText Actual setpoint by external temperature
S0011 ActualSptWR Actual setpoint by Water Reset
S0012 StatusFreeCooling FreeCooling 0=Off 1=On
S0013 GenWarning 0=Off 1=On
S0014 GenBlock 0=Off 1=On
S0015 NCompOnUnit Active compressors
