7 - CONTROL
HYDRONIC MODULE STATA
code description description
AO-965 %CmdInverter_X7 % value inverter command signal
DI-965 OvlP1.Hid_X4 Pump 1 overload 1 : 0=OK 1=Fault
DI-965 OvlP2.Hid_X5 Pump 2 overload : 0=OK 1=Fault
DI-965 OvlP3.Hid_X6 Pump 3 overload : 0=OK 1=Fault
DI-965 OvlInv.Hid_DL1 Inverter overload : 0=OK 1=Fault
DO-965 CmdP1.Hid_DO1 Pump 1 command : 0=Off 1=On
DO-965 CmdP1Inv.Hid_Q2 Pump 1 inverter command : 0=Off 1=On
DO-965 CmdP2.Hid_DO2 Pump 2 command : 0=Off 1=On
DO-965 CmdP2Inv.Hid_Q3 Pump 2 inverter command : 0=Off 1=On
DO-965 CmdP3.Hid_Q1 Pump 3 command : 0=Off 1=On
DO-965 ComdP3Inv.Hid_Q4 Pump 3 inverter command : 0=Off 1=On
DO-965 CmdInverter:X8 Hydronic inverter command: 0=Off 1=On
S0500 StartsP1Hidro Pump 1 starts
S0501 StartsP2Hidro Pump 2 starts
S0502 StartsP3Hidro Pump 3 starts
S0503 HoursP1.Hid Pump hours 1
S0504 HoursP2.Hid Pump hours 2
S0505 HoursP3.Hid Pump hours 3
S0506 HoursInverter.Hid Hydroni module inverter hours
ENERGY METER STATA
S0720: U12 L1 - L2 voltage
S0721: U23 L2 - L3 voltage
S0722: U31 L1 - L3 voltage
S0723: Freq Frequency
S0724: IL1 L1 current
S0725: IL2 L2 current
S0726: IL3 L3 current
S0727: Ptotale Current active power
S0728: Cosfi Total power factor
S0729: Energy Active energy totalized
S0730: THD-U12 Sum of harmonic components of voltage between L1 e L2
S0731: THD-U23 Sum of harmonic components of voltage between L2 e L3
S0732: THD-U31 Sum of harmonic components of voltage between L3 e L1
