42
7 - CONTROL
P.C. CONNECTION
1 connect P.C. and main module with LAN cable
2 check in the taskbar that the connection is active
3 Open Control panel and select Network and sharing center
4 Select Modify board setting
5 Select Local area connection (LAN)
6 Select Internet protocol version 4 (TPC) IPV4 and enter Property
7 Set the IP address 192.168.1.100
8 Set Subnet mask as 255.255.255.0
9
confirm (OK)
10 Enter Start (Windows button).
11 Write the command cmd and enter/do it
12 Write and run the command Ping 192.168.1.42
13 if will appear dawn an answer string, the connection is ok
14 enter the browser and the address 192.168.1.42
15
Userid = ADMIN
16
Password = SBTAdmin!
