CLIVET WSAT-XEE Series - Thermostatic C1 Stata; Recovery Circuit 1 Stata

39
7 - CONTROL
THERMOSTATIC C1 STATA
code description description
S1200 SHSpOp Overheating SetPoint
S1201 AICalSuctSprHtP Actual Overheating SetPoint
S1202 ECVState
0 = Idle 1 = ECVAlarm 2 = FailSafe 3 = Referencing 4 = Positioning 5 = Positioned 6 = ECVWaiting 7 =
FastClosing
S1203 EEV:SH_Limiter Max. opening valve
S1204 EEV:LET_Limiter Min. opening valve
S1205 EEVMode 0=Idle (motor off) 1=Init (valve closed) 2=Manual 3=Control
S1206 Prepos Thermostatic requested positioning
S1207 ECVSetPos % Opening valve if EEVMod = Manual
S1208 ECVMode 0 = Idle 1 = Init 2 = Position 3 = FastClose
S1209 SHPIDOut % Output PID value
S1210 EEVStatus
0 - Closed (Ready) 1 - StartUpPositioning 2 - StartUpPositioned 3 - SuperHeat 4 - Prepositioning 5 - MET 6 -
LET 7 - Closing 8 - PumpDown 9 - DangAlarm 10 - PumpDownStartUp 11 - ECVAlarm 12 - MinSHLmtr 13 -
WaitValveClose 255 - Warning
S1211 SetPosSteps Number of control steps that must reach the valve to adjust the superheat
S1212 SetPos% Valve % opening command to adjust the superheat
S1213 Pol94xCommOK Connection Status of the module POL94U : 0=NotOK 1=OK
S1214 ActPos% Actual position valve EEV
S1215 ActPosSteps Actual steps number valve EEV
S1216 ECVMode 0 = Idle 1 = Init 2 = Position 3 = FastClose.
S1217 ECVState
0 = Idle 1 = ECVAlarm 2 = FailSafe 3 = Referencing 4 = Positioning 5 = Positioned 6 = ECVWaiting 7 =
FastClosing
RECOVERY CIRCUIT 1 STATA
code description description
AI-965 P.OutRec_X7 Pressure value recovery circuit
AI-965 T.InH2ORec_X2 Recovery inlet water temperature
AI-965 T.OutH2ORec_X3 Recovery outlet water temperature
AI-965 T.OutGasRec_X1 Recovery gas outlet temperature
AO-965 %CmdPmpRec_X8 % 0-10vcc signal value recovery variable pump
DI-965 EnableRec_X4 Enabling recosvery input : 0=Fault 1=OK
DI-965 Ovl PmpRec_X5 Recovey thermal protection pump 0=Fault 1=OK
DI-965 FlowRec_X6 Flow recovery 0=Fault 1=OK
DI-965 SystemPress.Recovery_DL1 System pressure probe: 0=Fault 1=OK
DO-965 YV1Rec_DO1 Command valve YV1 0=Off 1=On
DO-965 YV2Rec_DO2 Command valve YV2 0=Off 1=On
DO-965 YV3Rec_Q1 Command valve YV3 0=Off 1=On
DO-965 YV4Rec_Q2 Command valve YV4 0=Off 1=On
DO-965 YV5Rec_Q3 Command valve YV5 0=Off 1=On
DO-965 PmpRec_Q4 Recovery pump command 0=Off 1=On
