Premium version (EN)
General technical data (EN)
Acoustic Treatment: extremely low noise (EN)
Size 352 402 432 452 502 552 602 702 802
Cooling
Cooling capacity 1 kW 87,0 95,9 105 115 126 136 153 178 193
Compressor power input 1 kW 29,9 35,3 39,9 42,1 45,7 51,6 59,8 64,3 74,4
Total power input 2 kW 32,4 37,8 42,4 44,6 48,2 54,1 62,3 67,8 77,9
Total recovery heating capacity 3 kW 114 129 144 155 169 186 208 238 263
Partial recovery heating capacity 3 kW 28,6 32,7 37,0 39,6 42,8 47,8 54,6 59,2 68,6
EER 1 2,69 2,54 2,48 2,58 2,62 2,51 2,45 2,62 2,48
Cooling capacity (EN14511:2013) 4 kW 86,5 95,3 105 114 125 135 152 177 192
Total power input (EN14511:2013) 4 kW 32,9 38,4 43,1 45,2 48,9 54,8 63,0 68,8 78,8
EER (EN 14511:2013) 4 2,63 2,48 2,43 2,53 2,56 2,47 2,41 2,57 2,44
ESEER 4 3,58 3,75 3,74 3,94 3,92 3,89 3,77 3,80 3,66
Compressor
Type of compressors SCROLL SCROLL SCROLL SCROLL
SCROLL SCROLL SCROLL SCROLL SCROLL
No. of compressors No 2 2 2 2 2 2 2 2 2
Rated power (C1) HP 35 40 43 45 50 55 60 70 80
Std Capacity control steps No 3 3 3 3 3 3 2 3 2
Oil charge (C1) l 8,00 10,0 12,0 10,0 11,0 13,0 13,0 13,0 13,0
Refrigerant charge (C1) 5 kg 18 18 22 24 27 27 32 39 39
Refrigeration circuits No 1 1 1 1 1 1 1 1 1
Internal exchanger
Type of internal exchanger 6 PHE PHE PHE PHE PHE PHE PHE PHE PHE
Water ow rate (Utility Side) 1 l/s 4,20 4,60 5,00 5,50 6,00 6,50 7,30 8,50 9,20
Internal exchanger pressure drops 1 kPa 40,7 41,7 43,9 41,2 37,2 38,5 41,2 39,5 42,5
Water content l 4,80 5,50 6,10 6,90 8,00 8,90 10,1 11,9 14,2
External Section Fans
Type of fans 7 AX AX AX AX AX AX AX AX AX
Number of fans No 2
2 2 2 2 2 2 3 3
Standard air ow l/s 10025 10025 10014 9986 9937 9937 10001 15015 15015
Connections
Water connections 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2 2” 1/2
Power supply
Standard power supply V 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50 400/3/50
Dimensions
A - Length mm 2710 2710 2710 2710 2710 2710 3075 4025 4025
B - Width mm 1097 1097 1097 1097 1097 1097 1097 1097 1097
C - Height mm 1805 1805 1805 1805 1805 1805 1805 1805 1805
Standard unit weights
Shipping weight kg 773 796 885 917 955 975 1077 1283 1310
Operating weight kg 778 802 892 924 963 984 1087 1295 1324
1. Data referred to the following conditions: internal exchanger water = 12/7 °C external exchanger inlet air 35°C
2. The Total Power Input value does not take into account the part related to the pumps and required to overcome the pressure drops
for the circulation of the solution inside the exchangers
3. Option. Recovery exchanger water = 40/45°C
4. Data calculated in compliance with Standard EN 14511:2013 referred to the following conditions: Internal exchanger water
temperature = 12/7°C. External exchanger intake air temperature = 35°C
5. indicative values for standard units with possible +/-10% variation. The actual data are indicated on the label of the unit.
6. PHE = plates
7. AX = axial fan
