46-80 Installation and User Guide V1.0
14
14. AUX OUT – line level outputs for Zone 1 and Zone 2. Outputs are balanced at 0 dBu, and are derived prior to the power
amplier stages.
15. SW3: UTIL/PRI/APD – 8-pole DIP switch for setting further unit congurations:
SWITCH FUNCTION PURPOSE
1
APD ON
Enables automatic standby mode
2
APD TIMING
Sets delay before entering APD mode
3
LINE 6: PRIORITY Z1
Enables Line 6 priority for Zone 1 only
4
LINE 6: PRIORITY ALL
Enables Line 6 Priority for all Zones
5
UNUSED
6
UTILITY SOURCE A
Select source for UTILITY/LOOP OUTPUT
7
UTILITY SOURCE B
8
UTILITY SOURCE C
16. SPEAKER OUTPUTS – amplier outputs for each of the four zones, on 2-pin 5 mm-pitch screw-terminal connectors per-
zone. Outputs will be low impedance (4 ohms) on Model 46-80, and either 70 V-line or 100 V-line (territory-dependent)
on Model 46-80T or on Model 46-80 if CXL-80T transformers have been retrotted.
17. UTILITY/LOOP OUTPUT - an auxiliary output carrying a mix of music and mic inputs, whose music source can be set
by DIP SWITCH SW3 [15]. The output is balanced, and at line level (0 dBu). The output has two associated preset level
controls, MIC and MUSIC.
18. RS232 - a 3-pin 3.5 mm-pitch screw-terminal connector providing a bi-directional RS-232 interface. This accepts
commands to select or adjust various 46-80 functions and parameters from an external AV control system.
19. MUSIC MUTE – 2-pin 5 mm-pitch screw terminal connector for connection of external emergency muting relay (e.g., re
control panel).
20. Mains – IEC receptacle for AC mains. The receptacle has an integral fuseholder. The 46-80 will operate on all AC supply
voltages from 85 to 243 V, 47 to 63 Hz.
21. Power switch.
