General
Power input 85 to 243 VAC, 47 to 63 Hz
Normal operating temperature
0 °C to 35 °C (Note: performance and specications cannot be guaranteed
outside of this range)
Power consumption
Standby
1
8.6 W, 27.5 VA
Idle
2
20.3 W, 38.6 VA
1/8
th
Power
3
Lo-Z output (4 ohms): 64.9 W, 85.2 VA
Hi-Z output (100 V into 125 ohms): 92 W, 109.7 VA
1/3
rd
Power
4
Lo-Z output (4 ohms): 126 W, 154 VA
Hi-Z output (100 V into 125 ohms): 176 W, 198 VA
Heat Loss
Standby
1
30.8 kJ/hr (29 BTU/hr)
Idle
2
72 kJ/hr (69 BTU/hr)
1/8
th
Power
3
Lo-Z output (4 ohms): 103 kJ/hr (98 BTU/hr)
Hi-Z output (100 V into 125 ohms): 187 kJ/hr
(177 BTU/hr)
1/3
rd
Power
4
Lo-Z output (4 ohms): 129 kJ/hr (122 BTU/hr)
Hi-Z output (100 V into 125 ohms): 287 kJ/hr
(272 BTU/hr)
Dimensions
Net
482.6 mm x 88 mm (2U) x 320 mm
19” x 3.5” x 12.6”
Shipping (Gross)
610 mm x 200 mm x 460 mm
24” x 8” x 18”
Weights
Net
46-80: 5.5 kg / 12.3 lbs
46-80T: 8.6 kg / 19.3 lbs
Shipping (Gross)
46-80: 8 kg / 17.9 lbs
46-80T: 11.1 kg / 24.9 lbs
Notes re Power Consumption and Heat Loss measurements:
All measurements at 230 VAC 50 Hz power input
1. Standby: amplier in standby state (STATUS LED steady red)
2. Idle: amplier not in standby state (STATUS LED steady green), but no audio output
3. 1/8
th
. Power: constant sound level at 10 W output (audio mainly clean, only occasional clipping)
4. 1/3
rd
. Power: constant sound level at 27 W output (audio beginning to become compressed, limited or heavily clipped)
