18
Turning Off the Router
1. On the Utilities screen, switch to Jog Mode by clicking on the [Jog] button.
2. Jog the machine to the tool changer side, press and hold the button on the spindle to release tool and put
that tool in the tool changing station.
3. Jog the Z-axis all the way up.
4. Close the Python software by click the top right X.
5. Shut down Windows.
6. Press the power button on the control cart.
7. Rotate the main contact switch to the OFF position.
8. Disconnect air from the router. Your drill block will drop down after air is disconnected.
As long as you jog the Z-axis all the way up BEFORE turning the machine off, it
should not hit your vacuum table.
Utilities Screen
Tab
Close
Window
Jog button
Z-axis controls
To Next Page
