7
The Emergency Stop or E-stop
The E-stop is a safety feature that stops all operations of the router. You have three (3) emergency stop buttons
that are easily accessible while the router is operating:
To initiate an emergency stop, press the red button. Once pressed, the controller & router safety lights will turn red
to alert you that your router is stopped.
Pressing the E-stop sends an electrical pulse to the entire router that shuts all operations down
instantly— we recommend using it sparingly for emergencies and should not be utilized to
pause or as a regular stop button, as frequent use may damage your motors.
On the controller
To turn the router back on from an E-stop, turn the E-stop
button clockwise, in the same direction as the arrows
shown. The red safety lights will then turn to white.
For those on the gantry, a green ring appears when the
E-stop is disengaged. When pressed and engaged, the
green ring will disappear.
On both sides of the gantry
