Executing your first (single) file
1. Turn the router on.
2. Save your design file into the CNC File folder.
• Save to the folder if designing from the controller
• Save to the folder after importing via USB
• Save to the folder after downloading from the internet (cloud, email)
3. Double click on the Python icon.
4. From the Main Screen, click on the [Operation] tab.
5. Click [Select File].
6. Select the file from the CNC file folder.
7. After you select the file, the top part of the screen should show the filename you selected
8. After you check that the filename is correct, check the material size. If not, click on the [Material
Selection] button to switch to your preferred size.
9. Then switch to the Utilities Page by clicking on the [Utilities] tab.
10. On the Utilities page, click on [Material Thickness] and specify the dimensions.
11. Press [Load] to load the material
12. Once the material is loaded and aligned, press the [Start] button to begin cutting.
