Appendix B: Command reference
98-143082-D AT commands 115
<evaluation
precedence
index>
<evaluation
precedence
index>
The evaluation precedence index defines the order in which the traffic flow
filters are applied to packets. 0 is first, then 1, 2 etc.
<Guaranteed
bitrate DL>
<Guaranteed
bitrate DL>
NA
The guaranteed bit rate down link (32, 64, 128).
Placeholder when Standard data is selected.
<Guaranteed
bitrate UL>
<Guaranteed
bitrate UL>
NA
The guaranteed bit rate up link (32, 64, 128).
Placeholder when Standard data is selected.
<Max bitrate DL> <Max bitrate DL>
NA
The maximum bit rate down link (32, 64, 128).
Placeholder when Standard data is selected.
<Max bitrate UL> <Max bitrate UL>
NA
The maximum bit rate up link (32, 64, 128).
Placeholder when Standard data is selected.
<p_cid> <p_cid> The primary context to which the secondary context is related.
<packet filter
identifier>
<packet filter
identifier>
The packet filter identifier (1 – 8).
<protocol
number>
<protocol
number>
This number is uniquely assigned for the protocol being used. TCP is set to 6,
and UDP is set to 17. The protocol number determines which protocol is
used by the traffic flow filter (0-255).
<protocol> <protocol> The transport protocol (IP or PPP).
<source addr &
subnet>
<source addr &
subnet>
This is an IPv4 IP address and subnet mask (0.0.0.0.0.0.0.0 to
255.255.255.255.255.255.255.255).
<source port
range>
<source port
range>
Source port range in the form From.To.
See above for example.
<state> 0
1
Deacativate.
Activate.
<Traffic Class> 1
3
Streaming (not available for M2M subscription).
Standard data (Background).
Parameter Values Meaning
