COBHAM SAILOR 6000 User Manual

Chapter 2: Installation
2-4
98-131571-B
Drilling and cutting template
2.2.2 Tabletop mounting for 3 x 400mm section
Cut for cable entry
400
25
400
4 mounting holes (ø6)
Cut for cable entry
25
NB! The table must be sufficiently supported
to carry the console.
****
400
4 mounting holes (ø6)
Cut for cable entry
4 mounting holes (ø6)
for 400mm section.
Drilling template
0 47.5 55 75 375 395 402.5 447.5 455 475 775 795 802.5 847.5 855 875 1175 1195 1202.5 1250
0
15
65
85
115
300
375
2.2.3 Bulkhead mounting for 2 x 400mm section
Earth stubs entry.
99-132410
100
0
405
300
*
*
**
**
for 400mm section.
Drilling template
Earth stubs entry.
100
**
25
25
400400
850
775 475 375 75 0
