Chapter 3: Electrical Installation3-2 98-131571-B
3.2 Console light
Theintentionistosupplytheconsoleworkplace,withsufcientambientlightforworking.Ifdesired,thelight
can be turned off completely, so that it does not distract the ship operator, for example during night time.
Howeverwhenrequiredthelightcanbeturnedonquickly,bymeansofaswitch.
Byturningthedimmingpotentiometerclockwise,thelightintensityincreases,andcorrespondinglyturningthe
potentiometercounterclockwisedecreasesthelightintensity.
Thelightcanbeswitchedoff,byturningthepotentiometerfullycounterclockwisepasttheclick.
ThegoosenecklampisfedbyaregulatedDCvoltage.Themax.voltagesuppliedtothegoosenecklampis
around 12VDC.
Thegoosenecklampcomprisea3pinXLR-plugwithareleasebutton.Pin2carriespositivesupplyvoltage(+),
pin 3 is connected to DC-. Pin 1 is not connected.
Thegoosenecklampsuppliedwiththeconsoleisofthetypeprovidingwhitelight.Agoosenecklampofred
lighttypeisavailablefromtheThrane&ThraneeShopidentiedasP/NS-29-127565-A.
3.3 Console Connection Box
The Console Connection Board is available build into a box, the SAILOR 6330, for use in installations not
featuring a SAILOR console. Providing the same connection possibilities the application of the SAILOR 6330
Console Connection Box will be simular to the application of the connction board in the SAILOR consoles, i.e.
one Connection Box for the primary side and one for the duplication side etc.
The Connection Box is supplied with the following interconnection cables, all of a length of 1 meter.
Identication Description Pcs
37-131079 Connection cable, 1x10 pole LTW 2
37-131080 Connection cable, 1x12 pole LTW 2
37-131081 Connection cable, 1x10 pole LTW 2
37-131510 NMEA 2K Micro Device Cable 2
Please refer to chapter 4 in this manual for details on how to connect the equipment using the SAILOR 6330
Console Connecton Box.
